Difference between Zigbee and Z wave

Hello, readers welcome to the new post. Here we will discuss the Difference between Zigbee and Z wave. Both of this technology work without the use of wires to make links among the different devices through the internet. For smart homes, these two are considered the primary measures. Mostly smart home appliances work on the Z-waves. Every home security company mostly offers the Z-wave control system.

These 2 wireless technologies are mostly employed at the industrial level. Since the 1970s are using in home security systems and other places. some differences exist in these two modules we will find based on different features. So let’s get started Difference between Zigbee and Z wave.

Table of Contents

What is Zwave

For home automation to make communication among the different devices Zwave protocol is used.
It offers less value of latency communication that is accurate for small-size data packets having data rates of 100KBits per second.

Its main operation is to transmit the signal and control the devices and uses mesh topology having compatibility to thirty-two nodes.
Its operating frequency is 908.42 megahertz which is different for different countries.
It used the GFSK Gaussian frequency sight keying and has control network controller modules and regulates the Zwave system.
Every Zwave consists of a network home Id and numerous node IDS for the devices that are under regulation
Its system configuration is simple that any user can handle it
Its structure is more expensive than the Zigbee
Its operation is slow speed than the Zigbee
It can handle 232 nodes
It can transmit data up to fifty meters
Its data rate is 9.6 to 100 kbps
It not according to any international standard

Zwave Applications

It used in home automation
Used in medical instruments for measuring the fitness levels
Used in smart energy systems
Used for remote control of devices
Employed in building automation

What is Zigbee

It is an open-source network and can be used with free access. Some Zwave suppliers also offer Zigbee services
that are compatible with IEEE 802.15.4 standards. It uses the 915 megahertz frequency in the USA and has some limitations for data and a data speed of 40Kbps is not good for this frequency value.

The frequency value of 2.4 GHz also offered the Zigbee. But these frequency values can cause interference to WIFI
Zigbee uses the same frequency values to WIFI but Zigbee smart home protocol is not the same to WIFI.
If we make a difference between ZigBee and wifi come to know that their uses is the main difference.
Zigbee uses to make connections among the smart home appliances and the main device called the hub while WIFI uses different techniques of encryption to secure the devices and make connections ot the WIFI router.
It needed some value of power and devices can work for 7 years at one group of battery
it is considered the finest option for a person who has good knowledge of technology
Zigbee is less expensive than the Zwave
Its operating speed is high than the Zwave
it can handle the sixty-five nodes
It uses BPSK and OQPSK modulation
It uses a 2.4 gigahertz bandwidth
its data rate is 40 to 250 kbps
Its configuration is more difficult than the Zwave

Zwave vs ZigBee

Zwave

Zwave is a communication protocol used to make connections between different devices as part of home automation.
It offers a basic system that can easily be set up.
It is a higher cost than ZigBee.
It is a slower method than ZigBee.
It is compatible with 232 end nodes or higher.
It uses the GFSK modulation method.
It can transmit data up to a 50-meter distance.
It works on the Sub1G band.
Its data rate support is 9.6-100 kbps.
It uses low energy and does not affect Wi-Fi.

Zigbee

It is an open standard wireless system.
It uses power and has worked for about more than 7 years.
It is lower cost than Zwave and high speed.
It supported 65000 end nodes.
Its modulation techniques are BPSK, OQPSK
It can transmit a signal for a 100-meter distance.
It works on a 2.4GHZ band and supports 40- 250 kbps.
It uses high energy and has interference for WIFi
It handle mesh network with more devices and operates fastly

Applications of Zigbee

It used in the automation and control of different devices
Home automation consists of this model
Gaming modules used this
It used in medical devices

Used for simple remote control

Zigbee pros and cons

Its operating speed is high
It can handle multiple devices inmesh system
The disadvantage is that can interface with IWFI since has the same frequency
It uses the high value of power

Z-Wave pros and cons

It does not interfere with WIFI
It uses less power than the Zigbee
Its operating speed is slow
It can interfere with the landline not having cords

Read also

That is all about the Difference between Zigbee and Z wave all details has covered if you have any queries ask in the comments, Thanks for reading have a nice day see you in next psot.
