Hello, readers welcome to the new post. In this post, we will discuss the CR1632 Lithium Battery. The battery is a device that is used to store electrical energy in the form of chemical energy. CR1632 is a lithium coin cell battery that is generally employed in different devices such as watches, and different toys, to operate them.
Here I further want to mention that if you are working on projects where you have to employ a CR1632 battery as your component to power all components used in the board. You must contact the creators of the most famous project and manufacturer that is PCBWAY. PCBWAY is china based PCB supplier that comes with the different categories of PCBs that you are also using in your projects can get through them with getting the design and components of projects that going to be constructed their technical team is always ready to help you in every aspect of your project and different services like design, etc.
You can get from PCBWAY component sourcing and PCBA service in just thirty dollars for twenty Pieces. With that, you can get from them the special offer that they give is only $5 for 10 standard PCBs (2 layers )within 100x100mm.
They also come up with a lead time for PCBA services of three to five days in $30/20 pcs. They also offer PCBA free stencils $15/piece
CR1632 Lithium Battery
Battery type is used for storing electrical energy in the form of chemical energy. CR1632 lithium cell battery used in small devices.
CR1632 is a non-rechargeable battery made with the use of lithium and manganese dioxide. It comes with a nominal voltage of 3V and a capacity of 130mA with a weight of 1.8 grams and its dimensions are diameter and 3.2 mm in height.
The shelf life of this battery is ten years at room temperature which reduces to five to six years if stored in high temperature.
With its small size, this battery offered high capacity and longer working life. So they have high weight-to-power ratio
CR1632 Pinout
- There are two main pinouts of this device first one is the positive and the second one is the negative.
- The top portion of this module is positive and the lower part is negative or cathode.
CR1632 Features
- The main features of this device are listed here.
- It is a non-rechargeable device
- Its weight is 1.8 grams.
- Capacity is one thirty milliampere hours.
- Its operating volts are three volts.
- The current value is 0.19 millimeters.
| Type |
button cell
|
| Chemistry | Lithium |
| Voltage | 3V |
| Diameter | 16mm |
| Thickness | 3.2mm |
| Capacity |
130 mAh
|
| Operating temperature |
-30°C to 60°C
|
| Shelf life |
10 years
|
| Self-discharge |
1% per year
|
CR1632 equivalent batteries
VL1632, , KCR1632, KECR1632, KL1632, ML1632, LiR1632, BR1632, DL1632, ECR1632and L1632.
CR1632 stand for
- C is the chemical composition of the battery is lithium
- R shows a round battery shape
- The 16 or first two numbers means the battery diameter in mm is 16mm
- The last two digits are the thickness of the battery which is 3.2mm
CR1632 vs CR2032
CR1632
- it is high voltage that is 3 volts battery
- it does not have mercury
- It has low self-discharge and a longer working life about ten years
- Working temperature is about (-30°C to +60°C)
- it has protection from leaking and high weight-to-power ratio
CR2032
- its voltage value is 3 volts.
- Working life is about ten years
- Full lineup used for different applications
- It not have mercury and high leak protection
- high weight-to-power ratio
| Features | CR1632 | CR2032 |
|
Nominal
|
140 mAh | 225 mAh |
|
Nominal Voltage
|
3V | 3V |
| Weight | 1.8g | 2.9g |
|
Operating Temperature
|
-30°C – +60°C | -30°C – +60°C |
| Released | 2005 | 2006 |
| Diameter | 16mm | 20mm |
CR1632 Applications
- Automotive
- Smart Key/Keyless entry
- Door sill strip
- IoT
- Tracking devices
- Sensors
- Security System
- Thermometers
- Home electrical appliances/Multifunctional printer
- POS systems
BR1632 Vs CR1632
| Features | BR1632 | CR1632 |
| composition | Lithium and Poly-Carbonmonofluoride |
Lithium and Manganese Dioxide
|
| Operating Temperatures | approx. 80°C |
60°C
|
| Application | low drain devices such as real-time clocks |
high drain devices such as keyless entry systems
|
What battery can I use instead of CR1632?
- The main replacement of CR1632 is BR1632 batteries since have the same voltage and size. BR1632 batteries do good work for high-temperature conditions and are best for different applications.
Is CR1632 the same as CR2032?
- CR1632 and CR2032 are the same and come with the same features. The nominal capacity they have is different. CR1632 is 140mAh capacity and Cr2032 is 225mAh. With that they have different dimensions and weights. CR2032 comes wth 20mm diameter and CR1632 has a diameter of 16mm.
What size is a CR1632 battery?
| Item dimensions L x W x H | 21 x 10 x 1 centimetres |
| Item weight | 8 Grams |
| Amperage | 3 Amps |
| Battery capacity | 120 Milliamp Hours |
What does CR mean in battery?
- Normally first letter is an alphanumeric code that defines battery types. The first letter LR is an alkaline battery, Battery with first letter CR is a lithium battery SR is Silver Oxide which contains heavy metals.
Can I use 2 CR1616 instead of CR1632?
- Cr1616 has a thickness of 1.6mm and CR1632 has a thickness of 3.2 mm thickness. So we cannot use them.
Can I use CR1620 instead of CR1632?
- The replacement of CR1620 with CR1632 is not good since the difference in thicknesses is two batteries. CR1620 has a thickness of 2.0 mm, and CR1632 is thicker at 3.2 mm
How many mAh is a CR2032 battery?
- 225 milliamp hours
